Output power : 5W each channel
Coverage : 200-400 sq meters ( covering distance ,depends on the area’s signal strength )
Body Size : 400*110*33mm
Packing size :
Antenna size : 210mm ( length )
Overall weight : 3.8Kg
ambient temperature : -40~55C
relative humidity : 35~85%
Power consumption : 200W
Power input : AC160V~240V
Power output : DC 24V
Installation height : 1.8m~2.5m
Installation environment : indoor
Shell material : Metal aluminum profiles
Channel by default :
Frequency 2: CDMA GSM 870-960MHz (2G + 4G band 5, band 6, band 8 , band 18 , band 19 ,band 26 )
Frequency 3: DCS 1800 ( 1800-1880MHz , for 2G + 4G band 3, band 9 )
Frequency 4: 3G 2100 (2100-2170MHZ , for 3G + 4G band 4, band 10, ) ,
Frequency 5: 5G 3400mHZ
Frequency 6: 5.8G ( 5725-5860MHZ )
Frequency 7: PCS 1900 ( 1900-2000Mhz )
Frequency 8: GPS 1500 ( 1560-1620mHZ for GPS L1,BEIDOU B1 , GLONASS G1 ,GALILEO E1 ) 4G 2600 (2500-2700MHZ ,for 4G band 38, band 41 and wireless transmitting )
Frequency 9: 4G 2300-2400mhz ( 4G and WIFI )
Frequency 10: 4G 2600 (2500-2700MHZ ,for 4G band 38, band 41 and wireless transmitting )
Frequency11 : wifi 5.1G : 5150-5350MHz
Frequency12 : Satellite : 1227.60MHz ( GPS L2 )
We can produce and adjust any kinds of frequency or band width according to your need
Frequencys of 4G for reference .
