Operating voltage: AC 110V-220V automatic power adjustment - DC 12V

Operating frequency range:
2G GSM :

890MHz--915MHz(Up link)

935MHz--960MHz(Down link)

2G DCS  :

1710-1785 ( UPLINK  )1805-1880 ( DOWNLINK )

Support below 4G (FDD) :

4G band 3 :1710-1785 ( UPLINK  )
1805-1880 ( DOWNLINK )

Below 4G (FDD )  may be supported  ,because they are within band :
4G band 9 :       1749.9-1784.9 ( UPLINK  )                     1844.9-1879.9 ( DOWNLINK )

Gain:  ≥68dB ( uplink ) ; ≥70 ( downlink )
Flatness: ≤ 3dB
Noise figure: ≤ 3dB
In wave ratio: ≤ 1.4 (V.S.W.R)
Device delay: 1μs
Spurious Radiation: ≤-39dBm

Power: 34-35dbm
Size (H x W x D):
