low-power digital analog hybrid receiver technology and advanced power management technology, BY using external ultra wide-band antenna, it can accurately realize acoustic, optical and vibration reminding, alarms for common civil UAVs, including fixed wing, DIY, traversing aircraft.
Performance
Mechanics
Electronics
Environment adaptability
Screen
#
Index
Parameter
Remark
1
Drone model that can be detected
DJI,AUTEL,FIMI,DAHUA,PowerVision,YUNEEC,UDIRC and other common brands of drones and some self-made FPVs and WiFi drones
2
Drone model that can be located
DJI Mavic,Air,Mini,FPV,Avata series
3
Frequency
900M,1.2G,2.4G,5.2G,5.8GHz
4
Range
1~10km radius
Varies due to environment and drone model
6
Altitude
0m~1000m
7
Drone swarm detection
≥5 drones
8
Detection result refresh time
4~6s
Varies due to environment and drone model
9
Azimuth error
≤1.5°(RMS)
10
Location error
≤10m
11
Ready to use
≤120s
1
Weight
≤20kg
Adaptor excluded
2
Size
(520mm*415mm*224mm)±2mm
Case closed
1
Power consumption
≤100W
2
External supply voltage
100 ~ 220V AC
3
Battery run time
≥4h
Dual batteries
1
Operating temperature
-20~65ºC
2
Storage temperature
-40~70ºC
3
Waterproof
IP65
Case closed
1
Screen size
10.1 inches
2
Resolution
1080P
1920*1200
